Our Australian-Made Water Tube Steam Boilers for Sale Australia-Wide

Our Range of Water Tube Steam Boilers

East Coast Steam build water tube boilers from 1500KW to 10,000KW to suit many different processes and environments with the use of the world’s best Weishaupt package burner from German. The reliability and control of the WT range are one of the best performers around.



Supported by the use of another world leader in the steam industry Spirax Sarco the completed boiler made in our Brisbane workshops, is world-class and built by quality Australian Tradesman and women. The WT range has been installed in many hospitals, food processors, dairies, soft drink producers and a wide variety of companies throughout Australia and overseas. The WT range can be tailored to suit a wide variety of processes and uses for steam.

Sky blue pipes | Queensland | East Coast Steam

Water Tube Boiler Information

MODEL - 150WT

SIZE: 1500KW
FUEL INPUT: 6750Mj/h
STEAM OUTPUT: 2320Kg/h
OVERALL HEIGHT: 3160mm

OVERALL WEIGHT: 7500KG
BASIC FOOTPRINT: 2400mm x 4000mm
MAXIMUM STANDARD PRESSURE: 2100KPA

MODEL - 200WT

SIZE: 2000KW
FUEL INPUT: 9000Mj/h
STEAM OUTPUT: 3100Kg/h
OVERALL HEIGHT: 3160mm

OVERALL WEIGHT: 9500KG
BASIC FOOTPRINT: 2400mm x 4400mm
MAXIMUM STANDARD PRESSURE: 2100KPA

MODEL - 250WT

SIZE: 2500W
FUEL INPUT: 11250Mj/h
STEAM OUTPUT: 3870Kg/h
OVERALL HEIGHT: 3160mm

OVERALL WEIGHT: 10000KG
BASIC FOOTPRINT: 2400mm x 4800mm
MAXIMUM STANDARD PRESSURE: 2100KPA

MODEL - 300WT

SIZE: 3000KW
FUEL INPUT: 13500Mj/h
STEAM OUTPUT: 4630Kg/h
OVERALL HEIGHT: 3425mm

OVERALL WEIGHT: 14000KG
BASIC FOOTPRINT: 2700mm x 5000mm
MAXIMUM STANDARD PRESSURE: 2100KPA

MODEL - 400WT

SIZE: 4000KW
FUEL INPUT: 18000Mj/h
STEAM OUTPUT: 6160Kg/h
OVERALL HEIGHT: 3425mm

OVERALL WEIGHT: 16500KG
BASIC FOOTPRINT: 2700mm x 5800mm
MAXIMUM STANDARD PRESSURE: 2100KPA

MODEL - 500WT

SIZE: 5000KW

FUEL INPUT: 22500Mj/h

STEAM OUTPUT: 7730Kg/h

OVERALL HEIGHT: 3425mm

OVERALL WEIGHT: 18500KG

BASIC FOOTPRINT: 2700mm x 6200mm

MAXIMUM STANDARD PRESSURE: 2100KPA

MODEL - 600WT

SIZE: 6000KW

FUEL INPUT: 27000Mj/h

STEAM OUTPUT: 9280Kg/h

OVERALL HEIGHT: 3425mm

OVERALL WEIGHT: 24000KG

BASIC FOOTPRINT: 3200mm x 6400mm

MAXIMUM STANDARD PRESSURE: 1750KPA

MODEL - 700WT

SIZE: 7000KW

FUEL INPUT: 31500Mj/h

STEAM OUTPUT: 10830Kg/h

OVERALL HEIGHT: 3425mm

OVERALL WEIGHT: 27000KG

BASIC FOOTPRINT: 3200mm x 7500mm

MAXIMUM STANDARD PRESSURE: 1750KPA

MODEL - 800WT

SIZE: 8000KW
FUEL INPUT: 36000Mj/h
STEAM OUTPUT: 12370Kg/h
OVERALL HEIGHT: 4100mm

OVERALL WEIGHT: 29000KG
BASIC FOOTPRINT: 3200mm x 7800mm
MAXIMUM STANDARD PRESSURE: 1750KPA

MODEL - 900WT

SIZE: 9000KW
FUEL INPUT: 40500Mj/h
STEAM OUTPUT: 13925Kg/h
OVERALL HEIGHT: 4100mm

OVERALL WEIGHT: 31000KG
BASIC FOOTPRINT: 3400mm x 8200mm
MAXIMUM STANDARD PRESSURE: 1750KPA

MODEL - 1000WT

SIZE: 10000KW
FUEL INPUT: 45000Mj/h
STEAM OUTPUT: 15470Kg/h
OVERALL HEIGHT: 4100mm

OVERALL WEIGHT: 35000KG
BASIC FOOTPRINT: 3400mm x 8800mm
MAXIMUM STANDARD PRESSURE: 1750KPA

MODEL - 900WT

SIZE: 9000KW
FUEL INPUT: 40500Mj/h
STEAM OUTPUT: 13925Kg/h
OVERALL HEIGHT: 4100mm

OVERALL WEIGHT: 31000KG
BASIC FOOTPRINT: 3400mm x 8200mm
MAXIMUM STANDARD PRESSURE: 1750KPA

MODEL - 1000WT

SIZE: 10000KW
FUEL INPUT: 45000Mj/h
STEAM OUTPUT: 15470Kg/h
OVERALL HEIGHT: 4100mm

OVERALL WEIGHT: 35000KG
BASIC FOOTPRINT: 3400mm x 8800mm
MAXIMUM STANDARD PRESSURE: 1750KPA

Our Water Tube Boiler Specifics

All the WT range is rated from and at 100OC feed water temperature

Available fuel types as standard natural gas, LPG, and diesel

Bio-gas is available as optional, including duel fuel

All boilers are built to AS2593 for unattended operation

More comprehensive information and diagrams are available on the application

2x250WT
